- Keys
- Number, type: 76, piano style
- Touch response: 2 sensitivity levels, off
- Sound source
- AHL (tri-element)
- Polyphony (maximum)
- 64
- Tones
- Built-in tones: 820
- Stereo sampled piano tones: Yes
- User tones100 (tone editor)
- Drawbar Organ function
- Number of drawbars: 9
- Preset Drawbar Organ tones: 50 (included in 820 built-in tones)
- User Drawbar Organ tones50
- Percussion: Second/third
- Click: On/off
- Rotary effect: Fast/slow (DSP)
- Digital effects
- Reverb: 10 types
- Chorus: 5 types
- DSP: 100 preset, 100 user
- Rhythms
- Built-in rhythms: 260
- User rhythms: 100 (Pattern Sequencer)
- Accompaniment
- 5 types
- Controllers: Start/stop, intro, normal/fill-in, variation/fill-in, synchro/ending
- Pattern sequencer
- Yes
- Rhythm editor
- -
- Song sequencer
- 17 tracks x 5 songs
- Approximate capacity: 30,000 notes
- Punch-in/-out: Yes
- Song controller: Play/stop, fast forward/backward, pause, repeat
- Metronome
- 0, 2, 3, 4, 5, 6 beats;
- tempo range: 30 to 255
- Audio recording/playback
- Yes
- Recording capacity: Up to 5 songs x 13 minutes
- Requirement: SD or SDHC memory card
- Mixer
- 32 channels + external input
- Registration setups (presets x banks)
- 96 (6 x 16)
- Music Presets
- 305
- User presets: 100
- One Touch Preset
- 250
- Auto Harmonize
- 12 types
- Arpeggiator
- 150 types
- Scale function
- 17 preset scales
- Scale fine tune: ± 99 cents
- Scale memories: -
- Octave shift
- ± 2 octaves
- Layer/Split
- Yes/Yes
- Transpose
- ± 1 octave (-12 to +12 semitones)
- Tuning control
- A4 = 415.5 to 440.0 to 456.9Hz
- Pitch Bend wheel
- Pitch Bend range: 0 to 12 semitones
- Modulation button
- Yes
- Sliders
- 9
- Dial/data entry wheel
- Yes
- Display
- LCD with backlit
- MIDI
- 16 part multi timbral, GM level 1 standard
- SD memory card slot
- SD or SDHC memory card,
- 2 GB to 32 GB
- Terminals
- Phones: 1, stereo standard jack
- Line OUT: 2 (L / MONO, R), standard jack
- Instrument IN: 1, standart jack
- Microphone IN: 1 standart jack
- Audio IN: 1, stereo mini jack
- Pedal: 1, standart jack
- USB port: Yes
- Speakers
- Size: 12 cm x 2 + 3 cm x 2
- Bass-reflex System: Yes
- Speaker on/off: Yes
- Amplifier: 2 x 7 W
- Power supply
- Batteries: 6 x size D
- AC adaptor: AD-A12150LW
- Dimensions
- (W x D x H): 1,161 x 385 x 147 mm
- Weight
- (w/o batteries): 8.3 kg
- Accessories
- included: AC adaptor (AD-A12150LW), music stand
- optional: Pedal SP-20, SP-3
